3. Remove light guide from handpiece by gently pulling it
straight out. Examine light guide ends for damage or
composite material adhering to the tip. Examine the light
shield for tears or distortion. Replace if any damage is
noted on either component.
* CaviCide ® , CaviWipes ®
Coltène/Whaledent Inc.
Handpiece and Charger Base
Cleaning:
1. Initial cleaning of handpiece must begin immediately after
use to prevent drying of soil and contaminants in and on
the device.
2. All exterior surfaces of the eye shield handpiece or
charger base may be wiped with CaviWipes
soaked in surface disinfectant to remove gross soil. Do
not allow cleaning solution to invade the interior of
these components since this may adversely affect the
electronics.
Disinfecting:
1. All exterior surfaces of the handpiece or charger base
must be wiped and wetted with CaviWipes
soaked in surface disinfectant.
2. Allow the CaviCide
surface for a minimum of 3 minutes. Do not allow the
disinfectant to dry on the surface.
Rinsing:
1. Using clean tap water on a clean cloth, wipe away
residual disinfectant.
Drying:
1. Use a clean dry cloth to dry the exterior surfaces. Do not
allow fluids to accumulate in the charger base socket as
this may adversely affect the electronics.
and Lysol ® are not registered trademarks of
®* or a cloth
®* or a cloth
®*
surface disinfectant to reside on the
EN
Light Guide (fiber optic glass)
Cleaning:
1. Initial cleaning of the fiber optic light guide must begin
immediately after use to prevent drying of soil and
contaminants in and on the device.
2. All exterior surfaces may be wiped with CaviWipes
cloth soaked in surface disinfectant to remove gross soil.
Use a soft brush to remove contaminants in the junction
between the glass rod and metal ferrule if necessary.
3. Clean thoroughly using an ultrasonic cleaner such as the
Coltène/Whaledent BioSonic
®
with BioSonic
Minimum cycle time 10 minutes.
Sterilizing:
Package in a FDA cleared wrap prior to sterilization. Sterilization
can be performed with either of the following cycles;
1. In a gravity autoclave at 132°C / 270°F for 15 minutes
with a 15 – 30 minute drying time.
2. In a pre-vacuum sterilizer at 132°C / 270°F for 4 minutes
with a 20 – 30 minute drying time.
Light Shield/Tacking Tip(Elastomer Rubber)
Cleaning:
1. Initial cleaning of the light shield must begin immediately
after use to prevent drying of soil and contaminants in
and on the device.
2. All exterior surfaces may be wiped with CaviWipes
cloth soaked in surface disinfectant to remove gross soil.
Examine the light shield for damage and discard if any
cuts, tears, or distortion is noted.
3. Clean thoroughly using an ultrasonic cleaner such as the
Coltène/Whaledent BioSonic
with BioSonic ®
Minimum cycle time 10 minutes.
S.P.E.C. 3 ® LED Curing LIght
®
Ultrasonic Cleaning System
UC32 Solution Concentrate or equivalent.
®
Ultrasonic Cleaning System
UC32 Solution Concentrate or equivalent.
®* or a
®* or a
