Siemens SIMOVERT MASTERDRIVES Motion Control Betriebsanleitung Seite 121

10.99
Contents
1 DEFINITIONS AND WARNINGS ..................................................................... 1-1
2 DESCRIPTION ................................................................................................. 2-1
3 FIRST START-UP ............................................................................................ 3-1
4 TRANSPORT, STORAGE, UNPACKING........................................................ 4-1
5 INSTALLATION................................................................................................ 5-1
5.1 Installing the unit ............................................................................................... 5-1
5.2 Installing the optional boards ............................................................................ 5-4
6 INSTALLATION IN CONFORMANCE WITH EMC REGULATIONS .............. 6-1
7 CONNECTING-UP............................................................................................ 7-1
7.1 Power connections............................................................................................ 7-4
7.2 Control connections .......................................................................................... 7-7
7.3 Fan fuses ........................................................................................................ 7-11
8 PARAMETERIZATION..................................................................................... 8-1
8.1 Parameter input via the PMU............................................................................ 8-2
8.2 Parameter input via the OP1S .......................................................................... 8-5
8.3 Parameter reset to factory setting..................................................................... 8-9
8.4 Parameterizing by download........................................................................... 8-10
8.5 Parameterizing with parameter modules ........................................................ 8-11
8.6 Motor lists........................................................................................................ 8-25
8.7 Motor identification.......................................................................................... 8-30
8.8 Complete parameterization............................................................................. 8-30
Siemens AG 6SE7087-6JD50
SIMOVERT MASTERDRIVES Operating Instructions
Contents
1
