10.99

Switch settings

7.3

Fan fuses

Siemens AG 6SE7087-6JD50
SIMOVERT MASTERDRIVES
Switch
S1
•
open
•
closed
S2
•
open
•
closed
Line voltage AC 380 V to 480 V
Order number
6SE7023-8ED51
6SE7024-7ED51
6SE7026-0ED51
6SE7027-2ED61
Manufacturer: FNQ-R:
Table 7-9 Fan fuses
Operating Instructions
Meaning
SCom1 (X300): Bus terminating resistor
•
Resistor open
•
Resistor closed
SCom2 (X101/10,11): Bus terminating resistor
•
Resistor open
•
Resistor closed
Fan fuse (F1 / F2)
FNQ-R-6/10
FNQ-R-6/10
FNQ-R-6/10
FNQ-R-6/10
Bussmann
Connecting-up
7-11
