Rating Plate; Date Of Manufacture - Siemens SIMOVERT MASTERDRIVES Motion Control Betriebsanleitung

10.99
NOTE

Rating plate

Date of manufacture

Siemens AG 6SE7087-6JD50
SIMOVERT MASTERDRIVES
The derating of the permissible rated current for installation altitudes of
over 1000 m and at ambient temperatures below 40 °C is calculated as
follows:
Total derating = Derating
K = K x K
1 2
It must be borne in mind that total derating must not be greater than 1!
Example: Altitude: 3000 m
Ambient temperature: 35 °C
⇒ Total derating = 0.845 x 1.125 = 0.95
Fig. 11-2 Rating plate
The date of manufacture can be derived as follows:
Character Year of manufacture:
J
K
L
M
Table 11-3 Assignment of characters to the month and year of manufacture
Operating Instructions
x Derating
altitude ambient temperature
Character
1997 1 to 9
1998 O
1999 N
2000 D
Technical Data
K = 0.845
1
K = 1.125
2
Unit designation
Unit control version
List of
unit options
Year of manufacture
Month of manufacture
Technology functions
released,
if a cross is entered
here
Month of manufacture
January to September
October
November
December
