Networking and configuring the EV charging box
Prerequisite
90
Operating instructions – AC SMART
► If no Ethernet cable was installed in the EV charging box during initial
installation, add another cable entry in the housing of the EV charging
box and insert a cable entry. Observe the Assembly and installation
instructions.
► Route the Ethernet cable through the cable gland and connect the cable to
Ethernet interface X3 of the control board in the housing cover.
► Close the EV charging box and screw the cover back on.
► Install the design frame, if available.
► Switch on the EV charging box.
The next steps:
– Adjust the network settings (assign an IP address), see Chapter 9.2.
– Configure the EV charging box in the web server, see Chapter 9.3.
9.2
Assigning the network settings and IP address
The EV charging box must be connected to a local network via LAN cable ,
see Chapter 9.1.
► Start your computer.
► Press the Win+R buttons.
The Execute window opens.
► Enter the command ncpa.cpl and confirm by pressing OK.
► Right click on the cabled network connection and click Properties.
Figure 9.2
Selecting the network connection
► Click internet protocol, version 4 (TCP/IPv4) and then click Properties.
