Operating the EV charging box
10.4 Stopping the charging process
During the charging process, the status LED is illuminated blue and pulsing.
You can stop the charging process before the vehicle is fully charged.
Both charging plugs will remain interlocked. The plug can only be removed
SOCKET variation
from the EV charging box once the plug on the vehicle is released.
Stopping the charging process without authentication
► To stop the charging process, observe your vehicle manual.
► Disconnect the vehicle from the EV charging box, see Chapter 10.3.
Stop charging after authentication via AC SMART App
► Start the AC SMART App.
► Select the EV charging box.
► Touch Stop charging process.
The charging process is stopped.
► Disconnect the vehicle from the EV charging box, see Chapter 10.3.
Stop charging after authentication via RFID-Tag
If the charging process was started with an RFID tag, the RFID symbol on the
EV charging box will be illuminated continuously white.
► Hold the RFID-Tag in front of the interaction surface of the EV charging
box.
After successful authentication, you will hear a rising sequence of tones. The
RFID symbol will be illuminated white and pulsing.
The charging process is stopped.
► Disconnect the vehicle from the EV charging box, see Chapter 10.3.
Stopping charging after authentication via web server
► Start the web server.
► Click Authorisation.
► Click Stop, to stop the charging process.
The status Disabled is displayed.
The charging process is stopped.
► Disconnect the vehicle from the EV charging box, see Chapter 10.3.
