Networking and configuring the EV charging box
100 Operating instructions – AC SMART
9.4 Connecting the EV charging box to an external
device (Modbus)
EV charging boxes in the AC SMART product family can be controlled via
Modbus RTU or Modbus TCP via an external management system. The
external management system is the client. The EV charging boxes are con-
figured as servers upon delivery. There may be only one client, but multiple
servers. The Modbus TCP interface can be used by LAN and WLAN.
► Commission an electrician.
► Observe the Assembly and installation instructions.
Connection via Modbus TCP (LAN)
The EV charging boxes in the AC SMART product family can be connected
to an external device via interfaces X2 or X3. Upon delivery, the Modbus TCP
interface is configured as follows:
Ethernet interface 100Base-TX according to IEEE 802.3u / 10Base-T
according to IEEE 802.3
Connection type RJ45 socket /Ethernet
Protocol Modbus TCP
Transfer rate 10/100 Mbit/s
Max. cable length 100 m
Recommended cable CAT-6
DHCP is deactivated upon delivery. The charging controller is accessible as
follows.
IP address 192.168.0.8
Port 502
Address 255
Also observe the Modbus register. The tables are available in our online
catalogue.
