3.5 Status LED and acoustic signals
The colour and flash pattern of the LED indicate the operational status of the
EV charging box.
LED state Meaning
Green
The EV charging box is switched on and ready for operation.
illuminated
Blue The EV charging box is in Bluetooth coupling mode with the
flashing AC SMART App.
Blue The EV charging box has detected a connection to a vehicle
illuminated and is ready for a charging process.
Blue
The charging process is running.
pulsing
White The EV charging box expects the authentication with an RFID
pulsing tag.
White
The LED indicates the position of the RFID interface.
illuminated
The EV charging box has detected a fault. The charging
Red
process was ended. For troubleshooting information, see
illuminated
Chapter 12.
The EV charging box has detected a fault. The charging
Red
process was ended. For troubleshooting information, see
flashing
Chapter 12.
Acoustic signal Meaning
Rising sequence of
The RFID tag was detected. The authentication was successful.
tones
Falling sequence of The authentication was not successful. The RFID tag is not
tones registered or not released.
For notes on troubleshooting, see Chapter 12.
