Starting the charging process (PLUG variation)
► Connect the charging cable to the vehicle.
The charging plug on the connected vehicle is interlocked. The status LED on
the EV charging box is illuminated blue.
If no authentication is configured, then the charging process will start
automatically. The status LED on the EV charging box is illuminated blue and
pulsing.
If user authentication is configured, additional steps are required and will
depend on the type of authentication, see Chapter 10.2.
10.2 Completing authentication
Authentication with the AC SMART App
► Start the AC SMART App.
► Couple the app to the EV charging box, see Chapter 9.7.
► Select the EV charging box.
► Touch Start charging process.
The charging process will start. The status LED on the EV charging box is
illuminated blue and pulsing.
Charging after authentication via RFID tag
The RFID symbol will be illuminated white and pulsing.
► Hold a registered RFID-Tag in front of the interaction surface of the EV
charging box.
After successful authentication, you will hear an ascending tone sequence.
The RFID symbol will be illuminated continuously white.
The charging process will start. The status LED is illuminated blue and
pulsing.
Charging after authentication via web server
► Start the web server.
► Click Authorisation.
► Click Start to release a charging process.
The status Enabled is displayed. The charging process will start. The status
LED on the EV charging box is illuminated blue and pulsing.
10.3 Separating vehicle from the EV charging box
Once the charging process is complete, the status LED will be illuminated
continuously blue.
► To release the charging plug on the connected vehicle, observe your
vehicle manual.
► Separate the charging plug from the vehicle.
The plug on the EV charging box will be released.
SOCKET variation
► Separate the charging plug from the EV charging box.
► Store the charging cable.
PLUG variation
► Store the charging cable on the Kabelablage of the EV charging box.
after charging
Operating the EV charging box
Operating instructions – AC SMART
105
