Bosch Rexroth MTA 200 Projektierung Seite 124

7-12
NC-CPU Karte
4. POWER MANAGEMENT SETUP (NC-CPU)
ACPI function :Disabled
Power Management :User Define
PM Control by APM :No
Video Off Method :DPMS
Video OFF After :NA
MODEM Use IRQ :NA
Doze Mode :Disabled
Standby Mode :Disabled
Suspend Mode :Disabled
HDD Power Down :Disabled
Throttle Duty Cycle :62.5%
PCI/VGA Act-Monitor :Disabled
Soft-Off by PWR-BTTN :Instant-Off
PowerOn by Ring :Disabled
Resume by Alarm :Disabled
IRQ 8 Break Suspend :Disabled
Abb. 7-13: Setupeinstellungen 4
5. PNP/PCI CONFIGURATION (NC-CPU)
PnP OS Installed
Resources Controlled by
Reset Configuration Data :Disabled
IRQ-3 assigned to
IRQ-4 assigned to
IRQ-5 assigned to
IRQ-7 assigned to
IRQ-9 assigned to
IRQ-10 assigned to
IRQ-11 assigned to
IRQ-12 assigned to
IRQ-14 assigned to
IRQ-15 assigned to
DMA-0 assigned to
DMA-1 assigned to
DMA-3 assigned to
DMA-5 assigned to
DMA-6 assigned to
DMA-7 assigned to
Abb. 7-14: Setupeinstellungen 5
ROM PCI/ISA BIOS (2A69KM2Q)
POWER MANAGEMENT SETUP
AWARD SOFTWARE,INC.
** Reload Global Timer Events **
IRQ3(3-7,9-15),NMI
Primary IDE 0
Primary IDE 1
Secondary IDE 0
Secondary IDE 1
Floppy Disk
Serial Port
Parallel Port
ESC:Quit
F1: Help
F5: Old Values
F6: Load BIOS Defaults
F7: Load Setup Defaults
ROM PCI/ISA BIOS (2A69KM2Q)
PNP/PCI CONFIGURATION
AWARD SOFTWARE, INC.
:No
Used MEM base addr
:Manual
:Legacy ISA
:Legacy ISA
:Legacy ISA
:Legacy ISA
:Legacy ISA
:Legacy ISA
:Legacy ISA
:Legacy ISA
:Legacy ISA
:Legacy ISA
:Legacy ISA
ESC:Quit
:Legacy ISA
F1: Help
:Legacy ISA
F5: Old Values
:Legacy ISA
F6: Load BIOS Defaults
:Legacy ISA
F7: Load Setup Defaults
:Legacy ISA
DOK-MTA200-BTV20.3A***-PR03-DE-P
Rexroth BTV 20.3A
:Disabled
:Disabled
:Disabled
:Disabled
:Disabled
:Disabled
:Disabled
:Disabled
:Select Item
PU/PD/+/-:Modify
(SHIFT)F2:Color
Setup CI7BM 1_0 CNC4.eps
:N/A
:Select Item
PU/PD/+/-:Modify
(SHIFT)F2:Color
Setup CI7BM 1_0 CNC5.eps
