1.10 Rev. A - Bosch Rexroth MTA 200 Projektierung

7-6
NC-CPU Karte
V 1.10 REV. A
Revision note
REV. A
DIMM Memory
Abb. 7-5: NC-CPU (CI7BMX) V 1.10 REV. A
Rexroth BTV 20.3A
AWARD
BIOS
BAT1
ON
1 2 3 4 5 6 7 8
CPU Frequency Selector
CI7BM Series V1.10
CI7BMX Interfaces and Coding V 1.10 Rev A.eps
DOK-MTA200-BTV20.3A***-PR03-DE-P
PC-104
CPU Fan
Battery
