Survey and construction

10
11
1
1. Steel lamellas
2. Gripping element - planum side (main clamping)
3. Griping depth adjustment
4. Side clamping
5. Gripping element - machine side (main clamping)
Main Gripping
Type
Width
580-1.470
(22¾"-58")
HVZ-GENIUS-II
600-1.400
(23½"--55")
*
= Opening width of the hydraulic clamp
5140.0042
2
For paver thickness
*
mm
50-160 mm
(2 - 6¾")
**
mm
** =
9
6. Height adjustment roller
7. Support for excavator quick-change adapter
8. Pushing-off device (ADV)
9. Hydraulic endless rotator
10. Handles for guiding the device
11. Sliding adapter
Side Gripping Width L
*
990-1.400 mm
(39"-55")
**
960-1.440 mm
(37¾"-55")
Gripping range (for stone layer dimensions)
V1
8
7
6
5
4
3
Working load Limit Dead Weight
(WLL)
332 kg (730
400 kg (880 lbs)
lbs)
