Safety Marking

PROHIBITION SIGN
Symbol Meaning
It is not allowed to stand under hanging loads. Danger to life!
Danger of squeezing the hands! Touch only at handles.
WARNING SIGN
Symbol Meaning
Danger of squeezing the hands.
REGULATORY SIGN
Symbol Meaning
Each operator must have read and understood the operating
instructions (and all safety instructions).
OPTIONAL
Be sure that the fork sleeves are mechanically fixed (with locking
screw and safety chain or rope) to the lifting device.
OPERATING INFORMATIONS
Symbol Meaning
5140.0042
Adjusting lever for side clamping (switch on or off)
Adjustment of the main clamping (ÖW 570 – 1.470 mm)
V1
6 / 45
Order-No. Size
2904.0210 Ø 30 mm
2904.0209 Ø 50 mm
2904.0204 Ø 80 mm
2904.0367 205 x 30 mm
Order-No. Size
2904.0221 30 x 30 mm
2904.0220 50 x 50 mm
2904.0107 80 x 80 mm
Order-No. Size
2904.0665 Ø 30 mm
2904.0666 Ø 50 mm
2904.0223 Ø 50 mm
2904.0222 Ø 80 mm
Order-No. Size
2904.0358 110x55 mm
2904.0543 280X100
