Safety
2
Safety
2.1
Definition skilled worker / specialist
Only skilled workers or specialists are allowed to carry out the installation-, maintenance-, and repair work on this device!
Skilled workers or specialists must have for the following points (if it applies for
this device), the necessary professional knowledge.
2.2
Explanation of basic concepts
Gripping range:
Gripping good (s):
Opening width:
Immersion depth:
Device:
Product dimensions:
Dead weight:
Carrying capacity/working
load limit (WLL*):
*
= WLL → (english:) Working Load Limit
2.3
Safety symbols
Danger to life!
Identifies imminent hazard. If you do not avoid the hazard, death or severe injury will result.
Hazardous situation!
Identifies a potentially hazardous situation. If you do not avoid the situation, injury or damage to property
can result.
Prohibition!
Identifies imminent a prohibition. If you do not avoid the prohibition, death and severe injury, or damage to
property will result.
Important informations or useful tips for use.
5140.0042
•
specify the minimum and maximum product measurements of the gripping good,
which can be gripped with this device.
•
is the product, which will be gripped or transported.
•
consists of the gripping range and the measure to drive over the gripping good.
gripping range + measure to drive over the gripping good = opening width
•
is the maximum gripping height of gripping goods, conditional of the height of the
gripping arms of the device.
•
is the description for the gripping device.
•
are the dimensions of the gripping good (e.g. length, breadth, height of the product).
•
is the own weight (without gripping good) of the device.
•
specify the maximum possible load capacity of the device (for lifting of gripping goods).
•
for mechanic
•
for hydraulics
•
for pneumatics
•
for electrics
