Parameterizing With Parameter Modules - Siemens simovert masterdrives Betriebsanleitung

Parameterization
8.8
NOTE
8-28
Downloaded from www.Manualslib.com
After the data set to be downloaded has been selected, if the
identification of the stored data set does not agree with the identification
of the connected unit, an error message appears for approximately 2
seconds. The operator is then asked if downloading is to be
discontinued.
Download
*1909199701
MASTERDRIVES MC
Yes: Downloading is discontinued.
No: Downloading is carried out.

Parameterizing with parameter modules

Pre-defined, function-assigned parameter modules are stored in the
units. These parameter modules can be combined with each other, thus
making it possible to adjust your unit to the desired application by just a
few parameter steps. Detailed knowledge of the complete parameter
set of the unit is not required.
Parameter modules are available for the following function groups:
1. Motors
2. Motor encoders
3. Control types
4. Setpoint and command sources
Parameterization is effected by selecting a parameter module from
each function group and then starting quick parameterization. A
parameter reset to the factory setting is performed and then, according
to your selection, the required device parameters are set to achieve the
required control functionality. The parameters necessary for fine
adjustment of the control structure (all the parameters of the respective
function diagrams) are automatically adopted in the user menu
(P060 = 0).
If parameter changes have already been carried out on the unit, it is
recommended that you carry out a parameter reset to the factory
setting prior to performing "Quick parameterization".
manuals search engine
P P
Download Error:
*1909199701 Different
MASTERDRIVES MC IDs
Operating Instructions
06.2006
2 s
MotionControl 00
Stop download?
#yes
no
6SE7087-6KN50 Siemens AG
SIMOVERT MASTERDRIVES
