Parameterization
P60
8-2
Downloaded from www.Manualslib.com
Menu level 1
Select via
P60 Menu Select
User parameters
Parameter menu
Fixed settings
Quick
parameterization
Board
configuration
Drive setting
Download
Upread/free access
Power section
definition
Fig. 8-1
manuals search engine
Menu level 2
(only on OP1S)
General parameters
Terminals
Communication
Control and status words
Setpoint channel
Motor/encoder
Control/gating unit
Sequence control
Diagnostics
Functions
Releases
Free blocks
Technology
P358 Key P359 Lock
Parameter menus
Operating Instructions
06.2006
Menu level 3
(only on OP1S)
SCom1/SCom2
Field bus interfaces
SIMOLINK
SCB/SCI
Motor data
Encoder data
Position control
Speed control
Current control
V/f open-loop control
Gating unit
Faults/alarms
Messages/displays
Trace
Basic positioner
Synchronism
Positioning
Setting up/MDI
By entering a password in P359,
access to the menus in the gray
shaded area can be prohibited to
unauthorized persons
