Cooling, power
requirement of fan,
sound pressure
level
Siemens AG
SIMOVERT MASTERDRIVES
Downloaded from www.Manualslib.com
The following values apply to units:
6SE7035-1TJ 0, 6SE7036-0TJ 0
= 5 corresponds to MASTERDRIVES Motion Control
= 7 corresponds to MASTERDRIVES Motion Control Performance 2
Fan voltage / frequency
Fan current-requirement
Flow
Sound pressure level IP00
Sound pressure level chassis in
IP20 - cabinet
Sound pressure level chassis in
IP42 - cabinet with dust filter,
400 mm high cabinet cover
The following values apply to units:
6SE7037-0TJ70, 6SE7038-6TK70
Fan voltage / frequency
Fan current-requirement
Flow
Sound pressure level IP00
Sound pressure level chassis in
IP20 - cabinet
Sound pressure level chassis in
IP42 - cabinet with dust filter,
400 mm high cabinet cover
The following values apply to unit: 6SE7041-1TK70
Fan voltage / frequency
Fan current-requirement
Flow
Sound pressure level IP00
Sound pressure level chassis in
IP20 - cabinet
Sound pressure level chassis in
IP42 - cabinet with dust filter,
400 mm high cabinet cover
6SE7087-6KN50
Operating Instructions
manuals search engine
Technical Data
[V / Hz] 230 / 50 230 / 60
[A] 2.45
[m 3 /s]
0.46
[dB(A)] 77
[dB(A)] 70.5
[dB(A)] 70.5
[V / Hz] 230 / 50 230 / 60
[A] 5.0
[m 3 /s]
0.6
[dB(A)] 80
[dB(A)] 76
[dB(A)] 74
[V / Hz] 230 / 50 230 / 60
[A] 12.8
[m 3 /s]
0.88
[dB(A)] 82
[dB(A)] 82
[dB(A)] 81
3.6
0.464
77.5
71.5
71
7.4
0.6
82
77
75
22
0.88
86
85
84
11-9
