Torque motors
1FW3
Siemens AG
SIMOVERT MASTERDRIVES
Downloaded from www.Manualslib.com
Input in Motor order
P099 number (MPRD)
1 1FW3201-1.H
2 1FW3202-1.H
3 1FW3203-1.H
4 1FW3204-1.H
5 1FW3206-1.H
6 1FW3208-1.H
7 1FW3AH150 gen. General template for customer-specific
8 1FW3AH200 gen. General template for customer-specific
9 1FW3AH280 gen. General template for customer-specific
10 1FW3281-1.G
11 1FW3283-1.G
12 1FW3285-1.G
13 1FW3288-1.G
14 1FW3281-1.E
15 1FW3283-1.E
16 1FW3285-1.E
17 1FW3288-1.E
18 to 30 for future applications
31 1FW3150-1.H
32 1FW3150-1.L
33 1FW3150-1.P
34 1FW3152-1.H
35 1FW3152-1.L
36 1FW3152-1.P
37 1FW3154-1.H
38 1FW3154-1.L
39 1FW3154-1.P
40 1FW3155-1.H
41 1FW3155-1.L
42 1FW3155-1.P
43 1FW3156-1.H
44 1FW3156-1.L
45 1FW3156-1.P
