Input in Motor order number
P096 (MPRD)
133 1FT6086-8WF7
134 1FT6086-8WH7
135 1FT6086-8WK7
136 1FT6105-8WC7
137 1FT6105-8WF7
138 1FT6108-8WB7
139 1FT6108-8WC7
140 1FT6108-8WF7
141 to 149 for future applications
Other types
150 1FT6108-8AF7
151 1FT6105-8SH7
152 1FT6136-6SF7
153 1FT6021-6AK7
154 1FT6024-6AK7
155 1FT6163-8SB7
156 1FT6163-8SD7
157 1FT6168-8SB7
158 to 159 for future applications
Compact
160 1FK7022-5AK71
161 1FK7032-5AK71
162 1FK7040-5AK71
163 1FK7042-5AF71
164 1FK7042-5AK71
165 1FK7060-5AF71
166 1FK7060-5AH71
167 1FK7063-5AF71
168 1FK7063-5AH71
169 1FK7080-5AF71
170 1FK7080-5AH71
171 1FK7083-5AF71
172 1FK7083-5AH71
173 1FK7100-5AF71
174 1FK7101-5AF71
175 1FK7103-5AF71
176 1FK7042-5AH71
6SE7087-6KN50
Operating Instructions
manuals search engine
Speed Torque Current
n [rpm] M [Nm]
n n
3000 46.0
4500 45.0
6000 44.0
2000 82.0
3000 78.0
1500 116.0
2000 115.0
3000 109.0
3000 37.0
4500 40.0
3000 145.0
6000 0.3
6000 0.5
1500 385.0
2500 340.0
1500 540.0
6000 0.6
6000 0.75
6000 1.1
3000 2.6
6000 1.5
3000 4.7
4500 3.7
3000 7.3
4500 3.0
3000 6.2
4500 4.5
3000 10.5
4500 3.0
3000 12.0
3000 15.5
3000 14.0
4500 2.2
Parameterization
Number
I [A] of pole
n
pairs
37.0 4
53.0 4
58.0 4
60.0 4
82.0 4
43.0 4
57.0 4
81.0 4
25.0 4
41.0 4
104.0 3
1.1 3
0.9 3
136.0 4
185.0 4
174.0 4
1.4 3
1.4 3
1.7 4
1.9 4
2.4 4
3.7 4
4.1 4
5.6 4
3.8 4
4.4 4
4.7 4
7.4 4
3.6 4
8.0 4
10.5 4
12.0 4
2.2 4
8-45
