Setpoint and command source
Terminal strip and motorized potentiometer
Type of control
V/f control
Ref speed
Analog output
+/- 10 V
-X101/11
-X101/12
Type of encoder:
Without encoder
Siemens AG
SIMOVERT MASTERDRIVES
Downloaded from www.Manualslib.com
r003 Output Volts
r004 Output Amps
r006 DC Bus Volts
Norm.
P353
n(max, FWD speed)
n(max, REV speed)
Accel Time Decel Time
P462.1 P464.1
AnaOut Scale
AnaOut Offset
P644.1
AA
A
y
y[V]=
D
6SE7087-6KN50
Operating Instructions
manuals search engine
-X101/1 P24
-X101/2 M24
1 = Operation
-X101/3
MOP Accel Time
0 = Fault
-X101/4
1 = Raise MOP
-X101/5
1 = Lower MOP
-X101/6
1-Edge = Acknowledge
-X101/7
-X101/8
1 = ON 0 = OFF1
Volts Curve1
P327
Ref Freq
P352
P452.1
Norm.
Boost
P325
P453.1
AnaOut Smooth
P642.1
P643.1
Disp Freq Conn
x
x
P643.1
100 %
(=Frequency actual value)
Parameterization
MOP Decel Time
P431 P432
MOP(max)
P421
MOPi(min)
P422
Conf MOP
P425
00x0 = ... Without storing after OFF
00x1 = ... Storing after OFF
U
.3 .4
.2
.1
.1 .2 .3 .4
f
Motor
encoder
Freq Curve1
P326
r043.2
Motor
3~
