Installation
Filters
5-6
Downloaded from www.Manualslib.com
The following filter mat is approved for use:
FIBROIDELASTOV made by DELBAG-Luftfilter GMBH
Technical filter data in accordance with DIN 24185:
Design
Filter class
Volumetric flow V
Initial pressure difference
End pressure difference
Average degree of separation
Dust storage capability
Fire behaviour (DIN 53438)
Heat resistance max.
Humidity resistance (rel. humidity)
Dimensions: 1000 x 1500 x 10 mm
Order No.: 16 065 81
Manufacturer:
DELBAG-Luftfilter GMBH
Holzhauser Straße 159
13509 Berlin 27
Telephone:
Fax:
100
80
60
40
20
0
0
Fig. 5-5
manuals search engine
(m
∆
p A Pa
∆
p E Pa
%
g/m
°C
%
(030) 4381-0
(030) 4381-222
2000 4000
Data sheet of the filter mat
Operating Instructions
06.2006
FIBROID ELASTOV 10
EU 2
3 2
/h) x m 2500 - 10000
9 - 46
300
72
2
-
F1/K1
80
100
6000 8000
Volumetric flow V [(m³/h) x m²]
6SE7087-6KN50 Siemens AG
SIMOVERT MASTERDRIVES
10000
