06.2006
NOTE
Siemens AG
SIMOVERT MASTERDRIVES
Downloaded from www.Manualslib.com
PMU
X300
Mount. pos. 1 (CUMC)
Encoder card in slot C
Aux. contactor, external
DC24 V supply X9
Mount. pos. 3
Mount. pos. 2
Fan supply X18:1/5
Shield connection
for control cables
Fig. 7-2
The 230 V fan must be supplied with AC 230 V externally via terminal
strip X18 1/5 on the PSU.
6SE7087-6KN50
Operating Instructions
manuals search engine
X108
X101
S1
X103
S2
Motor connection
Connection overview for type G
Connecting-up
DC link
connection
PE1 / GND
PE2 / GND
7-3
