Changeability of parameters

The parameters stored in the units can only be changed under certain
conditions. The following preconditions must be satisfied before
parameters can be changed:
Preconditions
•
Either a function parameter or a BICO
parameter must be involved (identified
by upper-case letters in the parameter
number).
•
Parameter access must be granted for
the source from which the parameters
are to be changed.
•
A menu must be selected in which the
parameter to be changed is contained.
•
The unit must be in a status which
permits parameters to be changed.
Table 8-2
The current status of the units can be interrogated in parameter r001.
Status (r001)
"Ready for ON" (09)
"Ready for ON" (09)
"Operation" (14)
Table 8-3
6SE7087-6KN50
Operating Instructions
manuals search engine
Preconditions for being able to change parameters
P053 Result
2 P222 Src n(act) can only be changed via the
PMU
6 P222 Src n(act) can be changed via the PMU and
SCom1 (e.g. OP1S)
6 P222 Src n(act) cannot be changed on account of
the drive status
Influence of drive status (r001) and parameter access (P053) on the
changeability of a parameter
Parameterization
Remarks
Visualization parameters
(identified by lower-case letters
in the parameter number)
cannot be changed.
Release is given in P053
Parameter access.
The menu assignment is
indicated in the parameter list
for every parameter.
The statuses in which it is
possible to change parameters
are specified in the parameter
list.
