Connecting-up
Type J - L:
X9 - external DC
24 V supply, main
contactor control
NOTE
WARNING
7-8
Downloaded from www.Manualslib.com
The 5-pole terminal strip is used for connecting up a 24 V voltage
supply and a bypass contactor.
The connection base is located easily accessibly on the DIN rail below
the slide-in unit of the electronics box.
The voltage supply is required if the inverter is connected up via a
bypass contactor.
The connections for the contactor control are floating.
Terminal
5
5
4
4
3 3
2
2
1
1
Connectable cross-section: 2.5 mm² (AWG 12)
Table 7-4
The excitation coil of the main contactor has to be damped with
overvoltage limiters, e.g. RC element.
The 230 V fan has to be supplied with AC230 V externally. The
connecting points are located on the fuse-disconnectors on the right
next to the DIN rail of X9.
The external 24 V voltage supply must meet the requirements for safety
separation (PELV electrical circuit = Protective Extra Low Voltage).
manuals search engine
Designation
Main contactor control Main contactor control
Main contactor control Main contactor control
n.c. Not connected
0 V Reference potential
+24 V (in) DC24 V ... DC30 V
24 V voltage supply
Connection of external DC 24 V aux. voltage supply and main contactor
control (type J-L)
Operating Instructions
06.2006
Meaning Range
AC 230 V
1 kVA
0 V
For current
requirement
see section
"Technical
Data"
6SE7087-6KN50 Siemens AG
