06.2006
Designation
Order number 6SE70...
Rated voltage
Input
Output
Rated frequency
Input
Output
Rated current
Input
Output
DC link voltage
Rated output
Aux. power supply
Aux. power supply
Pulse frequency
Derating curve
Load class II acc. to EN60146-1-1:
Base load current
Overload current
Cycle time
Overload duration
Losses, cooling, power factor
Power factor
Converter cosϕU
Efficiency η
Pulse frequency 5 kHz
Dissipated losses
Pulse frequency 5 kHz
Cooling air required
Sound pressure level, dimensions, weights
Sound pressure level [dB(A)]
Type of construction
Dimensions
Width
Height
Depth
Weight
Siemens AG
SIMOVERT MASTERDRIVES
Downloaded from www.Manualslib.com
31-0TE 0
[V]
[Hz]
[A]
110
92
[V]
[kVA] 61...76
[V] DC 24 (20 -30) (3.0 A without options; more with options)
[V]
[kHz]
< 0.92 ind. < 0.92 ind. < 0.92 ind. < 0.92 ind. < 0.92 ind.
0.97
[kW]
1.25
[m³/s] 0.10
69
E
[mm]
270
1050
350
[kg] 55
*)
With Z = F02; 2.5 kHz pulse frequency
= 5 corresponds to MASTERDRIVES Motion Control
= 7 corresponds to MASTERDRIVES Motion Control Performance 2
6SE7087-6KN50
Operating Instructions
manuals search engine
Value
31-2TF 0 31-8TF 0 32-1TG 0
DC 510 to 650 (-15 % / +10 %)
3 AC 0 ... rated input voltage x 0,64
---
0 ... 400
148 184 208
124 155 175
= rated direct voltage
82...103 102...128 115...145
AC 230 ±15 % (for the fan)
2.5 kHz / 5 kHz
*)
0.91 x rated output current
1.6 x rated output current
300 s
30 s
0.97 0.97 0.98
1.51 2.04 2.30
0.14 0.14 0.31
69 69 80
F F G
360 360 508
1050 1050 1450
350 350 350
65 65 155
Technical Data
32-6TG 0
254
218
143...181
0.98
3.00
0.31
80
G
508
1450
460
155
11-5
