X101 – Control
terminal strip
WARNING
NOTE
Siemens AG
SIMOVERT MASTERDRIVES
Downloaded from www.Manualslib.com
The following connections are provided on the control terminal strip:
♦ 4 optionally parameterizable digital inputs and outputs
♦ 2 digital inputs
♦ 1 analog input
♦ 1 analog output
♦ 24 V aux. voltage supply (max. 150 mA, output only!) for the inputs
and outputs
If the digital inputs are supplied from an external 24 V supply, this must
be referenced to frame X101.2. Terminal X101.1 (P24 AUX) may not
be connected with the 24V supply.
Terminal Designation
1
2
3
4
5
6
7
8
9
10
11
12
Connectable cross-section: 0.14 mm
Terminal 1 is at the top when installed.
Table 7-5
In the case of digital inputs, levels below 3 V are interpreted as low and
levels above 13 V as high.
The outputs of the customer terminal can assume undefined states
during power up/board initialization/execution time overflow, unless a
specific response has been expressly defined (and implemented in the
hardware) for these periods.
6SE7087-6KN50
Operating Instructions
manuals search engine
Meaning
P24 AUX Aux. voltage supply
M24 AUX Reference potential
DIO1 Digital input/output 1
DIO2 Digital input/output 2
DIO3 Digital input/output 3
DIO4 Digital input/output 4
DI5 Digital input 5
DI6 Digital input 6
AI + Analog input +
AI − Analog input −
AO Analog output
M AO Ground analog output
2
to 1.5 mm
Control terminal strip
Connecting-up
Range
DC 24 V / 150 mA
0 V
24 V, 10 mA / 20 mA
24 V, 10 mA / 20 mA
24 V, 10 mA / 20 mA
24 V, 10 mA / 20 mA
24 V, 10 mA
24 V, 10 mA
11 bit + sign
differential input:
Ω
± 10 V / Ri = 40 k
8 bit + sign
± 10 V, 5 mA
2
(AWG 16)
7-11
