06.2006
Fans, volumetric
flow, opening cross-
sections
Opening cross-section in
the roof section at the top
(also possible at the front
sections in the doors
(maybe with filters
situated behind them)
Siemens AG
SIMOVERT MASTERDRIVES
Downloaded from www.Manualslib.com
MLFB
Fan
Minimum volumetric flow [m
Minimum opening cross-section in the cabinet doors [m
Degree of protection IP00 to IP42
Minimum opening cross-section in the top cover [m
Degree of protection < IP20
Minimum opening cross-section in the roof section [m
Degree of protection IP22 to IP42
Table 5-1
and/or at the side)
Opening cross-
Fig. 5-6
6SE7087-6KN50
Operating Instructions
manuals search engine
3
/s]
Fans, volumetric flow, opening cross-sections
Partition measures
Installation
6SE7035-xTJ50
2 x RH28M
0.46
2
]
0.26
2
]
0.26
2
]
0.26
Direct partition
between the fan box
and the cabinet frame
from all 4 sides
Cabinet frame
Partition to adjacent
cabinets on the left,
on the right and at the
rear
5-7
