Parameterization
8-48
Downloaded from www.Manualslib.com
Input in Motor order
P099 number (MPRD)
46 to 60 for future applications
61 1FW3201-1.E
62 1FW3201-1.L
63 1FW3202-1.E
64 1FW3202-1.L
65 1FW3203-1.E
66 1FW3203-1.L
67 1FW3204-1.E
68 1FW3204-1.L
69 1FW3206-1.E
70 1FW3206-1.L
71 1FW3208-1.E
72 1FW3208-1.L
73 to 253 for future applications
Table 8-7
manuals search engine
Speed Torque
n [rpm] M
n
150
500
150
500
150
500
150
500
150
500
150
500
Motor list 1FW3
Operating Instructions
06.2006
Current Number
[Nm] I [A] of pole
n n
pairs
300 12 14
300 37 14
500 21 14
500 59 14
750 30 14
750 92 14
1000 40 14
1000 118 14
1500 65 14
1400 169 14
2000 84 14
1850 226 14
6SE7087-6KN50 Siemens AG
SIMOVERT MASTERDRIVES
