8 Remote control

The patient can use the remote control to change the behaviour of the product to a certain extent during everyday
use (e.g. while becoming accustomed to the prosthesis). At the next appointment, the prosthetist can trace the
changes using the adjustment software. In addition, information about the product (step counter, battery charge
level, etc.) can be called up.
INFORMATION
The language of the user interface (menus) and the configuration and number of MyModes can only be
changed/adapted using the adjustment software.
INFORMATION
The connection to the original remote control can no longer be established if the product is connected to another
remote control. As a result, the message "DEVICE DISCONNECTED" appears in the display of the original
remote control when the connection is established.

8.1 Controls on the remote control

8.2 Information shown on remote control display

C-Leg 3C98-3/3C88-3
1) Navigation key
Select menu options/ change settings/ start to establish connec­
tion
2) , Navigation keys
Call up additional menu options/set, change parameters
3) Display
Display of remote control battery charge level and the last connec­
ted product
4) Navigation key
Select menu options/ change settings
5) Enter key
Switch on remote control unit/confirm selection, menu option
6) Connections (under cover cap)
Charging receptacle for power supply connection
1. – Remote control battery charge level
2. – Charge level of battery for currently connected product
- Product is charging. The menu items "STATUS" and "DEVICE SET­
TINGS" cannot be called up. In addition, the product mode cannot be
changed.
3. 68% – charge level of battery for currently connected product, as a per­
centage
4. 1 – Mode currently set
„!" – Service interval elapsed
5. Black background – currently selected menu option, e.g.: "STATUS" or
selected function
6. – Menu locked
Certain menus are locked if, for example, the battery for the product is
being charged.
To leave a menu without saving changes, use the
symbol , and confirm this with the
Remote control
key to select the
key.
