Querying The Prosthesis Status; Extended Menu - Ottobock C-Leg 3C98-3 Gebrauchsanweisung

Adding component
INFORMATION
After the initial connection to the prosthesis has been established successfully, the app will connect automatically
each time it is started. No further steps are required.

9.4 Querying the prosthesis status

► When the component is connected, tap the symbol in the main menu.
→ The following options are displayed:
Menu option
TRIP: 0
STEP: 2
BATT.: 39
Service: 01/07/2015

9.5 Extended menu

Tap the symbol in the main menu. Components can then be added or deleted by tapping the "Manage compon­
ents" button.
C-Leg 3C98-3/3C88-3
1) Tap the "Add component" button.
→ The "Preparation" screen appears. The serial number of the com­
ponent should be entered here. This is located on the inside of the
frame and begins with the letters "SN".
2) Follow the subsequent instructions on the screen.
3) After the PIN code is entered, a connection to the prosthesis is estab­
lished.
→ While the connection is being established, 3 beep signals sound
and the symbol appears.
The symbol is displayed when the connection has been estab­
lished.
→ Once the connection has been established, the data are read from the
prosthesis. This process may take up to a minute.
The main menu will then appear with the name of the connected pros­
thesis.
Description
Daily step counter
Total step counter
Current prosthesis charge level, as a
percentage
Next recommended service
Remote control app
Possible actions
Reset the counter by tapping the
"Reset" button.
For informational purposes only
For informational purposes only
For informational purposes only
Ottobock | 77
