10.1.3 Sitting down

The resistance of the product while sitting down ensures that the knees bend evenly, thereby
supporting the contralateral side.
1) Position both feet side by side at the same level.
2) While sitting down, the user should distribute his/her weight evenly between both legs
3) Move the buttocks in the direction of the backrest and lean the upper body forward.

10.1.4 Sitting

INFORMATION
While sitting, the knee joint switches to energy saving mode. This energy saving mode is activated regardless of
whether the sitting function is enabled in the adjustment software or not.
If the patient is in a sitting position for more than two seconds (i.e. the thigh is close to hori­
zontal and there is no load on the leg), the knee joint switches the resistance to a minimum
in the extension direction.
If the sitting function is activated in the adjustment software and switched on via the remote
control or app, resistance is also reduced in the flexion direction.

10.1.5 Standing up

Flexion resistance is increased steadily while standing up.
1) Place the feet at the same level.
2) Lean the upper body forward.
3) Put the hands on armrests, if available.
4) Stand up with support from the hands while keeping weight evenly distributed on feet.

10.1.6 Walking up stairs

Walking up stairs step-over-step is not possible.
1) Hold the handrail with one hand.
2) Place the foot of the contralateral leg on the first step.
Bring up the leg with the prosthesis.

10.1.7 Walking down stairs

This function must be practised and executed consciously. Only when the sole is properly
positioned can the system react correctly and permit controlled flexion.
1) Hold the handrail with one hand.
2) Position the leg with the product on the step so that the foot projects halfway over the
3) Roll the foot over the edge of the step.
C-Leg 3C98-3/3C88-3
and use armrests, if available.
edge of the step.
→ This is the only way to assure a secure rollover.
→ This flexes the product slowly and evenly at the knee joint.
Use
Ottobock | 81
