Use
Parameter
SITTING FUNCTION
VOLUME

10.3.4 Overview of adjustment parameters in MyModes

The parameters in the MyModes describe the static behaviour of the prosthesis for a specific motion pattern such
as cross-country skiing. Damping behaviour is not automatically controlled and adjusted in MyModes.
The following parameters can be modified in MyModes:
Parameter
GAIN
VOLUME

10.4 Switching off the product

CAUTION
Using the product while switched off
Falling due to unexpected behaviour of the product because of changed damping behaviour.
► Before using the product, switch it on by connecting the power supply and battery charger.
In certain cases, e.g. for storage or transportation, the prosthesis can be purposely switched off. It can only be
switched on by connecting to a live outlet, a power supply and a battery charger.
Switching off
► Connect/disconnect the battery charger to/from the product 3x. A wait time of approx. 2 seconds is required
before disconnecting the battery charger again.
→ After disconnecting 3 times, a descending sequence of 5 beeps is emitted and the product is then switched
off.
Switching on
1) Connect the power supply with battery charger to the socket.
2) Connect the battery charger to the product.
→ The correct connection of the battery charger to the product is indicated by feedback (see Page 93).

10.5 Turning Bluetooth on the prosthesis on/off

INFORMATION
The Bluetooth of the prosthesis must be switched on to use the remote control or remote control app.
If Bluetooth is switched off, it can be switched on either by rotating the prosthesis or connecting/disconnecting
the battery charger. Bluetooth is then switched on for approx. 2 minutes. During this time, the app must be star­
ted and used to establish a connection. If desired, the Bluetooth of the prosthesis can then be permanently
switched on (see Page 86).

10.5.1 Switching Bluetooth on/off using the remote control

1) When a connection is established, use the
and confirm this with the key.
2) Use the , keys to select the menu option "BLUETOOTH". The current status is displayed.
3) By pressing the key, Bluetooth is either turned on permanently (ON) of turned off (OFF).
If Bluetooth is to be switched off, the remote control must be switched off after the key has been pressed.
4) To leave the menu without saving changes, use the
key.
86 | Ottobock
Adjustment soft­ Remote con­
ware range trol/app adjust­
ment range
0 to 4 0 to 4
Adjustment soft­ Remote con­
ware range trol/app adjust­
ment range
0 to 100 +/- 10
0 to 4 0 to 4
,
Meaning
Further information on the stance function
(see Page 80).
Activation/deactivation of the sitting function.
This function needs to be enabled in the
adjustment software.
Volume of beep signal for confirmation tones
Meaning
Value for speed at which flexion resistance
increases as the knee angle increases
Volume of beep signal for confirmation tones
keys to select the "STATUS" menu option in the main menu
key to select the symbol and confirm this with the
C-Leg 3C98-3/3C88-3
