Preparation for Use
Screw connection
Fitting for long residual limb
Lamination anchor with threaded connector

7.1.7 Flexion stop

The knee joint comes fitted with a flexion stop upon delivery. This reduces the maximum flexion angle by 8°, thus
preventing the socket from coming into contact with the hydraulic unit.
The flexion stop can be removed to increase the flexion angle. In this case, it must be ensured that the socket and
the hydraulic unit do not collide.
Removing flexion stop
1) Use an appropriate screwdriver to loosen the screws on both flexion stops (left and right of the piston rod).
2) Remove both flexion stops from the joint together with the screws.
INFORMATION: Do not reinsert the screws!
68 | Ottobock
Torque
10 Nm/89 lbf. In.
C-Leg 3C98-3/3C88-3
