Remote control

8.3 Initial connection between remote control and prosthesis

INFORMATION
The Bluetooth must be activated on the prosthesis prior to establishing a connection.
If Bluetooth is switched off, it can be turned on by turning the prosthesis upside-down or by connecting/discon­
necting the battery charger. Bluetooth is then turned on for approx. 2 minutes. The connection must be estab­
lished during this period.
1
1) Use the key to activate the remote control.
→ The start-up screen appears and shows the battery charge level of the remote control as well as the date
and time (see fig. 1).
2) Press the key to start a prosthesis search (see fig. 2).
INFORMATION: The remote control automatically switches off after 5 seconds if no other keys are
pressed.
→ The serial number of the prosthesis that was found appears in the display (see fig. 3).
→ If names of prostheses appear in the display, this means there are prostheses already saved in the remote
control. Continue with the steps described in the section "Managing prostheses" (see Page 72), sub-sec­
tion "Adding a new connection (prosthesis) (menu option 'PAIRING')".
3) Compare the serial number that is displayed to the serial number of the prosthesis you want to connect to.
INFORMATION: The serial number is located on the inside of the frame and begins with the letters
"SN".
If the serial number 000000000 is displayed (multiple prostheses within the range), use the , ,
enter the serial number of the prosthesis you want to connect to.
4) Confirm with the key.
→ Once the connection has been established, the data are read from the prosthesis (see fig. 4). This process
may take a few minutes.
→ The main menu is then displayed on the remote control and includes the name of the connected prosthesis,
the battery charge level of the remote control, the charge level of the prosthesis and the mode that is cur­
rently set (1 = basic mode).
INFORMATION: The name of the prosthesis can only be entered or changed using the adjustment
software.
INFORMATION
After the initial connection to the prosthesis has been established successfully, the remote control will connect
automatically each time it is turned on ( key followed by

8.4 Querying the prosthesis status

INFORMATION
This function is not available while the battery of the prosthesis is being charged. The
of the "STATUS" menu option.
70 | Ottobock
2 3
key). No further steps are required.
4
, keys to
symbol appears in front
C-Leg 3C98-3/3C88-3
