4. Identification

4.1 Nameplate

The nameplate states the operating data and approvals applying to the pump. The nameplate is fixed to the
side of the stator housing opposite the electronic unit.
Fit the additional nameplate supplied with the pump close to the pit.
Fig. 4 Nameplate
Pos. Description
1 Type designation
2 Product number
3 Approval
4 ATEX certificate number
5 IEC Ex description
6 IEC Ex certificate number
7 Production code (year/week)
8 Enclosure class to IEC
9 Maximum head [m]
10 Rated input power [kW]
11 Rated voltage
12 Speed [rpm]
13 Net weight [kg]
14 EAC approval*
* For Russia only.
** For Australia only.
8
Pos. Description
15 Run capacitor [μF]
16 RCM logo**
17 CE mark

Installation and operating instructions,

18
publication number
19 Ex description
20 Maximum installation depth [m]
21 Maximum flow rate [l/s]
22 Rated power output [kW]
23 Maximum current [A]
Cos φ, 1/1 load
24
25 Maximum liquid temperature [°C]
26 Frequency [Hz]
27 Insulation class
28 Production country
