10. Troubleshooting

Installation of the RSP protective impression cylinder jacket
Problem
Poor adhesion of the protective impression
cylinder jacket
No adhesion of the protective impression
cylinder jacket
Too strong adhesion of the protective
impression cylinder jacket
Initial operation of the RSP System 2.0
Problem
Impression of the diecutting form on the
impression cylinder
Damage to the base plate material
Tool above cylinder bearer height
The diecutting form collides with the grip-
pers
88
Operating Manual
Possible cause
The impression cylinder is soiled
Mark 3-surface (after perfection) from Hei-
delberg
Perfect Jacket Surface from Heidelberg
Protective impression cylinder jacket for
press "with perfection" used on polished
impression cylinder
Possible cause
Protective impression cylinder jacket not
installed
Excess pressure
Air pockets between the flexible die and
the grid sheet
Calibration sheet/packing sheet incorrect
thickness
The foil fixed to the blanket cylinder was
not taken into consideration
The diecutting form stuck in the gripper
edge of the grid sheet
Solution
Clean the impression cylinder prior to fix-
ing IPA
Protective impression cylinder jacket for
presses "with perfection"
No protective impression cylinder jacket
available
Protective impression cylinder jacket for
presses "with perfection"
Solution
Install protective impression cylinder jacket
Make-ready
Stick the flexible die on free of air pockets
(use the RSP nip pulley)
Correct the cylinder packing thickness
Correct the cylinder packing thickness,
remove the foil
Keep the edge of the gripper free when
mounting the grid sheet
