CITO RSP System 2.0 Bedienungsanleitung Seite 83

3. RSP Perforating Rules
Description Cut : pitch
4 tpi Perfo 6.0 : 0.7 mm
8 tpi Perfo 2.4 : 0.8 mm
12 tpi Perfo 1.4 : 0.8 mm
16 tpi Perfo 0.8 : 0.8 mm
18 tpi Perfo 0.7 : 0.7 mm
35 tpi Perfo 0.3 : 0.4 mm
50 tpi Perfo 0.2 : 0.3 mm
4. RSP Cutting Rules
(Fig. 2)
Description
Cut Rule
5. RSP Cutting Rules
(Fig. 3)
Description
Crease R1*
Crease R2**
* for creasing
** for creasing and cutting and/or perforating
1
(Fig. 1)
Unit
6 m
6 m
6 m
6 m
6 m
6 m
6 m
Unit
6 m
Unit
6 m
6 m
2
Operating Manual
3
83
