1. Design of the RSP System 2.0

50
Operating Manual
STOP STOP
Achtung Printstart! Attention Printstart!
Basisplatte zuerst an der Unfix and unclamp
Hinterkante lösen und ausspannen! Base Plate on rear edge first!
Atención Printstart! Attenzione Printstart!
c c
b a
GO! RSP System 2.0 GO!
patented
Basisplatte zuerst hier an der Unfix and unclamp Base Plate
Hinterkante lösen und ausspannen! here on rear edge first!
1 1
1. RSP base plate
a) Yellow special plastic plate
b) Locking hinges for hanging the RSP grid sheet or the RSP direct fit flexible die.
c) Marking for the positioning of the base plate at the print start line of the blanket cyl-
inder
2. RSP grid sheet
a) Dimensionally stable grid sheet
b) Cut-out for hanging the grid sheet onto the pins of the lower hinge section on the RSP
base plate.
c) Millimetre scale, circumferentially reduced in order to enable register-true mounting of
the RSP form outside the machine
d) Marking of gripper margin
3. RSP protective impression cylinder jacket, self-adhesive
Stainless steel sheet coated with a special adhesive tape for protection of the impression
cylinder for smooth and coarse impression surfaces (but not suitable for Perfect Jackets)
b
c a
d
2 2 3 3
