6. Positioning of the
RSP offset creasing matrices
78
Operating Manual
1
1
If the two transfer cylinders before and after the impression cylinder where you want to
put the creasing rules are equipped with a chrome jacket (TransferJacket), the packing
sheets under the chrome jackets have to be removed before!
•
With the RSP form mounted in register, the printing unit is set to print manually while
the machine stands still.
•
Remove the upper protective foil (TOP) from the offset creasing rule (Fig. 1).
•
Fix the offset creasing rule with the creasing channel side on the centre of the creas-
ing rule of the RSP form, then remove the protective paper from the backside of the
offset creasing rule (Fig. 2).
•
Inch
the
cylinder
impression
cylinder
Now the offset creasing rules will position automatically and in perfect register to the
impression cylinder when impression is thrown on.
2
2
backwards
so
that
the
roll
in
the
direction
3
blanket
cylinder
and
of
each
other
(Fig.
4
3
the
3).
