part of the door; this air partly cools down the
walls of the door. In the lower part of the com-
bustion chamber body there are feet (11) of
the device.
Description for figure 1.
1-Combustion chamber body, 2-Heat exchan-
ger body, 3-Fan unit, 4-Insulation, 5-Door,
6-Grate, 7-Ash pan, 8-Smoke conduit (exhaust
fume outlet), 9-Assembly flange, 10-Power
lead with a plug, 11-Feet (supports).
►►3. ASSEMBLY REQUIREMENTS
Before the assembly of the heater, become
familiar with the requirements of this manual
and the requirements of national and local re-
gulations.
The observance of the requirements mentio-
ned above at installation and operation of the
room heater guarantees the accomplishment
of heating parameters as well as long, safe
and failure-free operation.
It is recommended that the design of the in-
stallation and the assembly of the room heater
be performed by an installation company with
adequate licences, which, in consultation with
the chimney-sweeper specialist and fire safe-
ty specialist, taking into consideration the re-
quirements of this manual, will issue a written
opinion regarding:
► insulation and bearing capacity of the
ground within the heater's housing,
► requirements concerning the heater and
the ventilation of the room in which the hea-
ter's installation is anticipated,
► requirements concerning the exhaust fume
discharge system (chimney).
At the assembly of the heater, it is necessary
to take into account the requirements inclu-
ded in the applicable regulations, however,
the chimney-sweeper specialist and the fire
safety specialist may change or supplement
the relevant provisions.
WARNING! The works specified
below are performed exclusively by a
qualified employee of an authorised
technical service.
FOUNDATION
Place the device on an even, stable and non-
flammable ground with a sufficient bearing ca-
pacity of the ground to transfer its weight (ac-
cording to table 1). In the case of insufficient
bearing capacity of the ground, relevant steps
should be taken (for instance, use of plates for
load distribution) in order to obtain the suffi-
cient bearing capacity.
The CT50P room heater may be connected
only to an individual chimney.
The smoke conduit of the heater must be con-
nected to the exhaust pipe in a way ensuring
tightness.
The chimney flue must be calculated on the
basis of draught demand values, mass stre-
am and temperature of exhaust fumes accor-
ding to table 1. For the existing chimney, if the
draught value exceeds the value from table 1,
provide a regulator maintaining the negative
pressure with a set value with an accuracy of
± 2Pa.
The maintenance of the chimney draught
within the recommended values is one of the
most important factors guaranteeing that the
technical-operational parameters of the hea-
ter will be obtained.
WARNING! If inflammable mate-
rials are mounted on the walls of the
room in which the heater is to be in-
stalled, it is prohibited to mount the
heater at distances smaller (measu-
red from the external walls of the
most protruding parts) than the ones
given in table 2. The chimney spe-
cialist and fire safety specialist may
change or supplement the relevant
provisions.
While determining the minimum distances, the
fan unit must be mounted. Apart from meeting
the requirements related to the minimum distan-
ces, the heater should be installed in such a way
as to ensure the free inflow of air to the fan unit
and the outflow of hot air from the device.
Check whether the cleaning and maintenance
activities may be performed without any pro-
blems.
VENTILATION
WARNING! In the room where the
en
