WARNING! Never disconnect the
device from the mains, when it is hot,
as the collected heating power in the
heat exchanger may damage the fan
and the heat exchanger.
TYPE OF HEATING
After starting the device, control its operation.
Successively add fuel in order to maintain the
operating parameters. Do not leave the device
without control
In the case of observing abnormal operation of
the device or its failure, cause the fire in the fur-
nace to be damped. Remove the cause of ab-
normal operation or failure.
(See table 1. Defects, causes and method of re-
moval).
WARNING! Parts of the heater – in
particular, external parts, are hot du-
ring operation, and adequate caution
is desirable.
IGNITION OF SOOT IN THE CHIMNEY !!!
Ignition of soot in the chimney signifies the igni-
tion of particles collected inside the chimney flue
(exhaust pipe), which were accumulated during
the operation of the heater, and were not clea-
ned by chimney sweepers.
In the case of occurrence of fire in the chimney:
► Call the Fire Brigade, clarifying in details what
DEFECTS
The fan is not operable 1. The device is not connected to the mains.
2.Problem with the power supply voltage.
3. Damaged power lead.
4. Mechanical interlock of the fan.
5. Damaged fan.
Smoke coming from the 1. Untight chimney installation.
device is present inside 2. Bad or choked room ventilation.
the room 3. Ash pan is filled up.
4. The device is overheated – the fan is not operable or its
operation is not correct.
Liquid is leaking from 1. Wet fuel.
the device
NOTE: POSSIBLE REPAIRS MUST BE PER-
FORMED BY AUTHORISED SERVICE THAT
USES ORIGINAL PARTS. IT IS PROHIBITED
TO OPEN AND MANIPULATE THE DEVI-
CE, EXCEPT FOR THE ACTIVITIES WHICH
ARE SUBJECT TO CHECKING DURING THE
MAINTENANCE.
is happening and how to get to a given building
► Damp the fire by careful removal of the in-
flammable material and tight closure of the fur-
nace
► Use the chimney sieve - it is a metal net with
mesh size of about 2 x 10 mm, at best copper,
spread over the frame with dimensions of 60
x 60 cm, with two metal holders. Protect the
chimney outlet with the sieve and observe the
lower parts of the chimney whether there are no
cracks through which the flames may get out.
Prevent the fire spread. Apart from this, the hea-
ted sieve decreases the draught in the chimney,
which causes the intensity of soot burning to be
decreased.
► Pour salt into the chimney outlet on the bur-
ning soot.
► Do not extinguish the fire in the chimney with
water, as the sudden cooling of the chimney and
water evaporation may cause chimney cracks
and spread of the fire.

VENTILATION MODE

In order to use only the fan mounted in the devi-
ce, connect it to the mains.
At the end of the heating season disconnect
the air heater and perform the relevant mainte-
nance activities.
Table 1. Defects, causes and method of remo-
val.
CAUSES
If the power lead which cannot be disconnected
is subject to damage, it should be replaced at
the manufacturer's or at a specialist's repair
workshop or by a qualified person in order to
avoid risks.
Also, make sure that the electrical parameters
of the power supply source correspond to the
technical data from the manual or the data ap-
METHOD OF REMOVAL
1.1. Connect the device to the mains.
2. Check the voltage in the power supply socket.
3. Replace the power lead
4. Remove the interlock.
5. Replace the fan.
1. Make the chimney installation tight
2. Improve the patency or make the ventilation patent.
3. Empty the ash pan. Clean the grate
4. Check the operation of the fan. If it is not operable, see
the defect – fan is not operable.
1. Use dry fuel.
