EN
Packaging was produced with environmental
responsibility and recycling in mind. Please sort waste
according to local regulations.
OPERATION
Before starting training, make sure the device is properly assembled.
•
Before starting your first workout, familiarize yourself with all
the functions and adjustment options of the device.
•
The device has parts that may be exposed
to corrosion. For this reason, it is not recommended to leave it
in a humid room. You should also ensure that the equipment
(especially its internal and electronic components) is not
exposed to water, drinks, sweat, etc.
•
The device is intended for training only by adults and is
absolutely not a toy for children. If you allow children to use it
at your own risk, be sure to instruct them on proper use and
supervise them constantly.
•
The equipment is not suitable for therapeutic purposes.
•
During the operation of the device, there may be quiet noises
during the inertial movement of the flywheel mass, which
result from the type of construction. They have no impact
on the operation of the equipment.
• Noise emission during load is greater than without load.
• Before each workout, check the correctness of the safety
devices and screw and plug connections.
• When training on the device, remember to wear appropriate
footwear (sports shoes).
EQUIPMENT MAINTENANCE
Maintain the device regularly. Perform the following activities at least
every 20 hours of its operation.
• Check the moving parts of the device. If they are not
sufficiently lubricated, use bicycle bearing grease.
• Check the condition of elements such as screws and nuts.
Make sure they are well tightened.
• After each workout, wipe sweat from the device. Pay attention
to ensure that the monitor does not come into contact with
water or moisture.
• Use only water
and soap to clean the device. Do not use cleaning agents.
•
Store the device in a dry and warm place.
•
Do not expose the device to sunlight.
BATTERY REPLACEMENT
Poorly visible information on the computer display or its absence
indicate the need to replace the batteries.
Remove the battery cover and replace the old ones with two new
ones. Placing them
in the battery compartment, observe the "+" and "-" markings.
If the display does not work properly after restarting, remove the
batteries for a few minutes and then reinsert them.
NOTE! Used batteries are not covered by the warranty. They contain
harmful substances (such as cadmium, mercury, or lead), so do not
throw them into the household waste container. Take them to the
appropriate collection point for used batteries.
ENVIRONMENT
The device is delivered in packaging to protect it from possible
damage during transport. Packaging are raw materials and can be
recycled. Dispose of these materials in the appropriate colored
containers for selective collection.
Protect the environment and do not throw used
batteries into the household waste bin. Return them to
the place of purchase or hand them over to a separate
collection point for recyclable materials.
Used electrical equipment (including the counter, power
supply) are recyclable materials - do not throw them
into household waste containers, as they may contain substances that
are dangerous to health and the environment. We ask for your active
help in economical management of natural resources and protection
of the natural environment by handing over the used device to a
collection point for recyclable materials - used electrical equipment.
ASSEMBLY
The assembly of the device must be carried out carefully by an adult. If
in doubt, ask someone for help with more experience in this field.
• Before starting the assembly, make sure that the set
with the device contains all the elements from parts list and
whether any elements have been damaged during transport. If
there are missing parts or concerns, please contact
the seller.
15
• Familiarize yourself with the drawings and explanations and
assemble in accordance with the order contained in assembly
instructions.
• Be careful during assembly. While using
tools and parts, there is a risk of injury.
• Remember to maintain a safe environment.
Do not scatter tools and assembly elements chaotically.
Remember that plastic films and bags pose a risk of suffocation
for children.
• Assembly elements needed to perform a given step assembly
instructions are shown in the drawings
and explanations. Use the elements indicated in assembly
instructions.
• In the early stages of assembly, do not tighten the parts
completely. Do this after placing all the parts and making sure
they are properly seated.
• The manufacturer reserves the right to pre-assemble certain
elements.
ASSEMBLY DIAGRAM (→ See page 2)
NOTE! It is forbidden to use parts from sources other than the
manufacturer.
PARTS LIST
NO. DESCRIPTION
1 Monitor
2 Welding of the support pipe
3 Screw
4 Screw M5*5
5 Bottle cage
8 Handrail welding
9 Screw M8*12
10 Spring washer D8
11 Flat washer D8
12 Handrail cover
13 Standing tube welding
15 L-shaped springwheel knob
16 Main frame welding
30 Screw M8*20*S6
31 Curved washer d8*Φ20*1.5*R28
36 Front lower support welding
37 Rear lower support welding
38 Seat tube welding
39 Nut
40 Flat washer φ10.5*φ30*3
42 Welding of the adjusting seat
43 Seat
44(R/L) Pedal
45 Nut
54 Screw ST4.2*12
A Wrench S13-14-15
B Wrench S5*30*80
C Wrench S17-19
ASSEMBLY INSTRUCTION (→ See page 2)
ATTENTION! During assembly, follow the steps below and use the
tools included with the product.
Prepare enough free space to assemble the device. Due to the heavy
weight of some parts, it is recommended to assemble it with two
people.
ADJUSTMENTS
Resistance adjustment
To increase the resistance, turn the resistance adjustment knob
clockwise.
To reduce the resistance, turn the tension adjustment knob
counterclockwise.
Seat height
QUANTITY
1
1
2
3
1
1
4
8
4
1
1
2
1
4
4
1
1
1
1
1
1
1
2
2
2
1
1
1
