HeartStart Intrepid Instructions for Use Addendum
Figure 7
Hold and pull the latch on the red handle to fully extend the mounting base of the docking station.
2
See
Figure 8
Place the HeartStart Intrepid into the mounting base of the docking station, aligning the docking
3
station adapter with the outline on the docking station. Ensure that the four guiding pins on the
docking station engage the docking station adapter. See
Figure 9
Plug the AC power cable plug into the AC connection of the HeartStart Intrepid. See
4
6
Unlocking the Docking Station
Figure 8.
Pulling the Latch
Mounting the HeartStart Intrepid
Figure 9.
.
Figure 10
