8
EINSTELLMODUS
Connectors
» SET > Connectors > Keyboard/Mouse
MENU
Keyboard [F1]-[F8] (VOICE)
Keyboard [F1]-[F8] (KEYER)
Keyboard Type
Keyboard Repeat Delay
Keyboard Repeat Rate
Mouse Pointer Speed
Mouse Pointer Acceleration
» SET > Connectors > USB DIAL
MENU
USB DIAL Select
USB DIAL Auto TS
USB DIAL [TRANSMIT] Switch
» SET > Connectors > CI-V
MENU
CI-V Baud Rate
CI-V Address
CI-V Transceive
CI-V USB/LAN→REMOTE Transceive Address
CI-V Output (for ANT)
CI-V USB (A) Echo Back
CI-V USB (B) Echo Back
(Standard: OFF)
(Standard: OFF)
(Standard: English)
(Standard: 250ms)
(Standard: 10.9cps)
(Standard: MID)
(Standard: ON)
(Standard: Only SUB)
(Standard: High)
(Standard: Push to toggle)
(Standard: Auto)
(Standard: B2h)
(Standard: ON)
(Standard: 00h)
(Standard: OFF)
(Standard: OFF)
(Standard: OFF)
» SET > Connectors
MENU
USB (B) Function
SEND Relay Type
ACC BAND Voltage Output
MIC Input DC Bias
PTT Port Function
REF IN
8-5
(Standard: RTTY/PSK Decode)
(Standard: MOS-FET)
(Standard: TX)
(Standard: ON)
(Standard: PTT Input)
(Standard: OFF)
