1. Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer
We hope your new device brings you much enjoyment
and success.
Note:
In accordance with the applicable product liability laws,
the manufacturer of this device assumes no liability for
damage to the device or caused by the device arising
from:
• Improper handling
• Non-compliance with the operating manual
• Repairs carried out by third parties, unauthorised
specialists
• Installing and replacing non-original spare parts
• Improper use
• Failures of the electrical system in the event of the
electrical regulations and VDE provisions 0100, DIN
57113 / VDE 0113 not being observed
Note:
Read the whole text of the operating manual before as-
sembly and commissioning.
This operating manual should help you to familiarise
yourself with your product and to use it for its intended
purpose.
The operating manual includes important instruc-
tions for the safe, proper and economic operation of
the product, for avoiding danger, for minimising repair
costs and downtimes and for increasing the reliability
and extending the service life of the product.
In addition to the safety instructions in this operating
manual, you must also observe the regulations appli-
cable to the operation of the product in your country.
Keep the operating manual package with the power
tool at all times and store it in a plastic cover to pro-
tect it from dirt and moisture. They must be read and
carefully observed by all operating personnel before
starting the work.
The product may only be used by personnel who have
been trained to use it and who have been instructed
with respect to the associated hazards.
The required minimum age must be observed.
22 | GB
In addition to the safety instructions in this operating
manual and the separate regulations of your country,
the generally recognised technical rules relating to the
operation of such products must also be observed.
We accept no liability for accidents or damage that
occur due to a failure to observe this manual and the
safety instructions.
2. Product description (fig. 1 - 13)
1. Handle (protective cover)
2. Handle (swivel frame)
3. Feed rocker
4. Pressure spring
5. Swivel frame lock
6. Wheel
6a. Washer
6b. Washer
6c. Split pin
7. Locking pin
8. On/off switch
9. Plastic insert
10. Longitudinal stop
11. Star knob screw (length stop)
12. Star knob screw (rocker extension)
13. Rocker extension
14. Saw blade
14a. Hexagonal nut
14b. Rocker guide
14c. Spring split pin
14d. Washer
14e. Screw
14f. Washer
14g. Saw blade flange
3. Scope of delivery
Item
6
6a / 6b
6c
www.scheppach.com
Quantity Designation
1x Rocking log saw
2x Wheel
4x Washer
2x Split pin
1x Spanner SW18 (not shown)
Operating manual
