Diese Anleitung gilt für folgende Ersatzteil-Kits:
Teil 2 von 2
A5 51512705 KIT CPA474 SPÜLSTUTZ. G1/4" PVDF
A5 51512706 KIT CPA474 SPÜLSTUTZ. NPT1/4" PVDF
J8/1 51512709 KIT CPA474 Antrieb pneumat. komplett
J8/2 51512710 KIT CPA474 ANTR. PNEU.KPL ELEKTR
J1 51513001 KIT CPA473/474 pneu. Hubrohr KCl L 425mm
J1 51513002 KIT CPA473/474 manuel Hubrohr KCl 425mm
J1 51513005 KIT CPA473/474 pneum.,Hubrohr Gel 360mm
J1 51513006 KIT CPA473/474 manuell, Hubrohr Gel360mm
J1 51517522 Spritzschutzkappe für Armaturen
J7 51518483 Dichtungssatz EPDM fuer CPA474 > 2005.5
J7 51518484 Dichtungssatz Viton für CPA474 > 2005.5
J7 51518485 Dichtungssatz Kalrez fuer CPA474 > 2005.5
J5 71042130 KIT CPA473/474 Zylinder PA lang
J5 71042134 KIT CPA473/474 Zylinder 1.4404 lang
J6 71064624 CPA471...5 Dichtungen ohne Mediumkontakt
J7 71069835 Kit CPA474 EPDM o. Abstreif:Dichthüls>2005.5
J7 71069846 Kit CPA474 Viton o.Abstreif: Dichthüls > 2005.5
J7 71069849 Kit CPA474 Kalre o.Abstreif: Dichthüls > 2005.5
J7 71082093 Kit CPA474 DN50 PVDF: Dichtleiste > 2005.5
J7 71082095 Kit CPA474 DN50 PEEK: Dichtleiste > 2005.5
J7 71082096 Kit CPA474 DN50 PP: Dichtleiste > 2005.5
J7 71082097 Kit CPA474 ANSI 2" PVDF: Dichtleiste > 2005.5
J7 71082100 Kit CPA474 ANSI 2" PEEK: Dichtleiste > 2005.5
J7 71082101 Kit CPA474 ANSI 2" PP: Dichtleiste > 2005.5
J1 71099157 KIT CPA473 KCl-ROHR PNEUMATISCH
J1 71099159 KIT CPA473 KCL-ROHR HAND
71217190 Manual kits CPA474
105
Kits Retractable process assembly Cleanfit CPA474
This instruction applies to following spare part kits:
Part 2 of 2
A5 51512705 KIT CPA474 rinse connectors 1/4" PVDF
A5 51512706 KIT CPA474, rinse connectors NPT1/4"
J8/1 51512709 KIT CPA474 Actuation pneumat. complete
J8/2 51512710 KIT CPA474 Actuat. pneum. compl. electr.
J1 51513001 KIT CPA473/474 pneum, re. pipe KCl 425mm
J1 51513002 KIT CPA473/474 manual re. pipe KCl 425mm
J1 51513005 KIT CPA473/474 pneum. re.pipe gel 360mm
J1 51513006 KIT CPA473/474 manual, re.pipe gel 360mm
J1 51517522 Splash protection cap for assemblies
J7 51518483 O-Ring set EPDM for CPA474 > 2005.5
J7 51518484 O-Ring set Viton CPA474 > 2005.5
J7 51518485 O-Ring set Kalrez for CPA474 > 2005.5
J5 71042130 KIT CPA473/474 cylinder PA long
J5 71042134 KIT CPA473/474 cylinder 1.4404 long
J6 71064624 CPA471...5 all seals w/o medium contact
J7 71069835 Kit CPA471 EPDM w/o scraper: sleeve > 2005.5
J7 71069846 Kit CPA471 Viton w/o scraper: sleeve > 2005.5
J7 71069849 Kit CPA471 Kalrez w/o scraper: sleeve > 2005.5
J7 71082093 Kit CPA474 DN50 PVDF: Raised face > 2005.5
J7 71082095 Kit CPA474 DN50 PEEK: Raised face > 2005.5
J7 71082096 Kit CPA474 DN50 PP: Raised face > 2005.5
J7 71082097 Kit CPA474 ANSI 2" PVDF: Raised face > 2005.5
J7 71082100 Kit CPA474 ANSI 2" PEEK: Raised face > 2005.5
J7 71082101 Kit CPA474 ANSI 2" PP: Raised face > 2005.5
J1 71099157 Kit CPA473, KCI pipe pneumatic
J1 71099159 Kit CPA473 KCl-pipe manual
