Replacement part numbers

13. Replacement part numbers
1. List of replacement part numbers
with designation 174 + 177
172 172
Replacement
Designation
part no.
1103 Auxiliary spindle with chuck
1104 Main spindle with chuck
1105 Pinion z = 21
1106 Pinion z = 32
1108 Base plate
1111 Drill depth stop M 12 x 1
1112 Metal guide plate
1114 Fence, 800 mm
1115 Base profile 465 mm
1116 Guide screw M 6 x 12
1120 Cap for chuck
1134 Auxiliary spindle quick-release chuck
1135 Main spindle quick-release chuck
1151 Deep groove ball bearing 6000 - RS
1155 Compression spring PM
Angled screw connection 1/8 "
1160a
(longer shank)
1161 Knock-in socket ø 10 x 12
1164 Square nut DIN 562 - M 8
1183 Pinion z = 17
1184 Special deep groove ball bearing 607 - 2RS
1190 Special auxiliary spindle with chuck
1193 Pinion z = 25
1197 Pinion z = 23
1223 Grip bar for swivel unit
1247 Threaded stud DIN 553 - M8 x 40
1248 Large-diameter washer DIN 9021- A 8.4
1249 Self-locking hexagon nut DIN 982 - M 8
1250 Bush
1251 Knob
1252 Spring washer DIN 2093 B 22.5 GR 1
Angled screw connection M 5 swivelling
1264
ø 4 mm
1353 Cap for quick-release chuck
Motor with switch = following information must be provided:
1. Machine type
1551
2. Serial number
3. Voltage, hertz, phases, power output in kW
Feather key for coupling
1553
DIN 6885 - A 3 x 3 x 16
1637 Coupling for piston rod, including nut
1638 Control panel
1651 Pneumatic cylinder DW 80 / 125
1656 5/2-way pushbutton valve 1/8 "
173 173
Replacement
Designation
part no.
1659 Angled screw connection 1/4 "
1661 Push-fit straight screwed connection 1/8" ø 6 mm
1662 Sound absorber 1/8 "
1663 Discharge air non-return valve, throttle-type
1664 Reduction nipple 1/41 x 3/8 A
1665 Servicing unit assy 1/4"
1671 Coupling plug NW 7.2
Electro-pneumatic switch with cable =
following information must be provided:
1680
1. Serial number
2. Voltage, hertz, phases, power output in kW
1684 Plug ø 6 mm
1686 Plug ø 4 mm
1688 Rapid bleeder valve G 1/8"
1689 Reduction nipple 1/8" l x 3/8" A
1690 Angled screw connection, tapered, 2 x 1/8"
1738 Pressure plate for hold-down clamp
1741 Bolt for hold-down clamp
1757 Pneumatic round cylinder, ø 33 mm
Plug connector, twin connection
1760
ø 6 mm
1763 Sound absorber M 5
Plug connector, twin connection
1765
ø 4 mm ( 3 x ø 4 mm)
1766 Push-fit cross connection ø 4 mm
1779 3/2-way valve M5, spring-returning
1783 Push-fit reducing connector
1953 5/2-way valve 1/8"
1955 3/2-way foot valve 1/8"
1956 Double nipple M5-M5
Push-fit angled screw connection R 1/8
1964
ø 4 mm MR 14.04.18
2001 Skiffy machine foot, grey polyethylene
2002 Work surface, BlueMax Mini Modular
2003 Centre stop 39
2004 Insert for work surface
2005 Grooved nut M long
2006 Guide column, BlueMax Mini Modular
2007 Bridge, BlueMax Mini Modular
2008 Valve plate for PC104 valve series
2009 Motor mount, BlueMax Mini Modular
2010 Tensioning spindle, BlueMax Mini Modular
2011 Pipe for discharge air, BlueMax Mini Modular
2012 Sliding plate, BlueMax Mini Modular
