Start-up / trial run

6. Start-up / trial run

1. Before first-time use

2. Safety check

3. Malfunctions on start-up

4 Machine versions supplied

1. Machine with article numbers:

9 131 498 and 9 131 499

2. Machine with article number: 9 132 099

5. Optional accessories

6. Interchangeable drilling units

Interchangeable drilling unit, 9 spindles,

Interchangeable drilling unit, 3 spindles, Selekta /
Interchangeable drilling unit, 6 spindles
Interchangeable drilling unit, 9 spindles
Interchangeable drilling unit, 90°, 9 spindles

7. Installing, assembling and connecting

8. Assemblies

Press-in frames for the interchangeable drilling unit,
6 spindles
Centre stop
Continuation stops
Drum stops
Hold-down clamp
Converting from manual operation to foot pedal
Connection assignment
9. Connecting to extractor system
Connecting to compressed-air supply
Connecting to power supply
10. Carrying out trial run
Pushbutton:
Information on trial run
Preliminary conditions
11. Concluding start-up
122
1. Before first-time use
Note:
122 The machine is started up for the first time and
inspected for acceptance by skilled personnel from
122
Hettich FurnTech GmbH & Co. KG.
122
Before the machine is started for the first time, make sure the
described basic settings and trial runs have been made and
123
the machine is ready for operation.
The following checks must be made before start-up:
123
• check the machine for correct installation and alignment,
123
• check all screw connections at the various stations for
123
secure fit,
123
• check the safety guards for proper working order and
• check the power and compressed-air connections for proper
connection and secure fit.
123
2. Safety check
123
Satisfy yourself that:
123
• installation, set-up and servicing work have been completed
123
in full and no persons are present in the danger zone, let
124
alone working on it,
• all safety guards / covers are in place,
124
• the compressed-air supply is ready for operation, and
125
• the controls are freely accessible.
126
3. Malfunctions on start-up
129
On start-up, immediately switch OFF the power supply to the
130
machine if:
131
• unusual operating noises can be heard,
132
• the machine runs irregularly, oscillates or vibrates,
132
• tools malfunction,
133
• auxiliary units malfunction
133
• the motors consume too much power
134
• there are electrical faults, and
134
• tools overheat.
134
134
135
Danger!
Never put this machine into operation if work is still
being performed on this machine or on the electrics.
Establish the cause of any malfunction with the machine shut
down and made safe and have it rectified by a qualified and
skilled person trained to do so or eliminate the malfunction
yourself if you are in possession of the necessary qualification.
Caution!
Only switch the machine back on again once
malfunctions / faults have been properly and
completely rectified!
4 Machine versions supplied
The machine comes in various versions.
1. Machine with article numbers: 9 131 498 and 9 131 499
Compact automatic drilling and insertion machine with
interchangeable drilling unit
• Pneumatic stroke movement, adjustable machine bench
• Mechanical drilling stroke limiter
• 2 drum stops for 22, 37, 57 mm depth adjustment of the
fence
• 1 interchangeable drilling unit with 6 spindles and quick-
change chuck
• 6 drill holders for quick-change chuck
• 1 tool shelf
• 2 pendulum stops
Electrical equipment:
• 1.1 kW / 400 V / 50 Hz / 3 phases 9 131 498
• 1.6 kW / 230 V / 60 Hz / 1 phase 9 131 499 1
2. Machine with article number: 9 132 099
Compact automatic drilling and insertion machine with
interchangeable drilling unit
• Pneumatic stroke movement
• Adjustable machine bench
• Mechanical drilling stroke limiter
• 2 drum stops for 22, 37, 57 mm depth adjustment of the
fence
• 1 interchangeable drilling unit, 6 spindles and quick-change chuck
• 6 drill holders for quick-change chuck
• 1 tool shelf
• 2 hold-down clamps (left / right)
• 1 centre stop with scale
• 2 continuation stops (left / right)
• 2 pendulum stops
Electrical equipment:
• 1.1 kW / 400 V / 50 Hz / 3 phases
5. Optional accessories
Accessories for customising the
BlueMax Mini Modular
• Hold-down clamp 9 131 508 1 set
• Centre stop with scale 9 132 098 1 each
• Press-in frame for drilling unit 9 132 100 1 each
• Foot pedal 9 132 101 1 each.
• Continuation stops 9 132 103 1 set
• Chuck plug for
quick-change chuck 0 040 657 1 each
• Chuck plug 0 076 497 1 each
6. Interchangeable drilling units
Interchangeable drilling unit, 9 spindles, interchangeable
drilling unit,
3 spindles, Selekta / interchangeable drilling unit, 6
spindles
Interchangeable drilling unit with three drilling spindles for
drilling holes for Selekta hinges (23/9).
Interchangeable drilling unit with 6 drilling spindles for
drilling holes for hinges and connecting fittings
• Interchangeable drilling unit, 3 spindles,
Selekta drilling pattern 9 131 503 1 each
• Interchangeable drilling unit, 6 spindles 9 131 501 1 each
• Interchangeable drilling unit, 6 spindles,
with quick-change chuck and
drill holders 9 131 500 1 each
Interchangeable drilling unit, 9 spindles
Interchangeable drilling unit for System 32 hole line drillings,
set of drill bits, interchangeable drilling unit, 9 spindles,
• Interchangeable drilling unit, 9 spindles 9 131 506 1 each
• Interchangeable drilling unit, 9 spindles,
with quick-change chuck and
drill holders 9 131 505 1 each
Interchangeable drilling unit, 90°, 9 spindles
Interchangeable drilling unit, offset 90° for drilling holes
for runners in System 32
• Interchangeable drilling unit, 90°,
9 spindles, 9 132 097 1 each
• Interchangeable drilling unit, 90°, 9 spindles,
with quick-change chuck and
drill holders 9 131 507 1 each
7. Installing, assembling and connecting
The BlueMax Mini Modular comes in secure shipment
packaging for safe transportation. A number of components
must be installed to make the machine ready for operation.
After installing the machine, clean off shipping dust and
remove preservatives (oil).
The following pages explain how to put together and install
individual assemblies.
Depending on your machine's equipment, specific skills are
required to carry out this work properly.
