7.5.2
Beschreibung des MQTT-Protokolls
Gruppe
Text
Modem / GPRS
Initializing and detecting modem...
Modem / GPRS
Modem could not be detected
Modem / GPRS
SMS system started
Modem / GPRS
Modem port opened at x baud
Modem / GPRS
Baud changed to x, reopening com port
Modem / GPRS
Modem detected: x
Modem / GPRS
Telit modem driver started
Modem / GPRS
CREG is x
Modem / GPRS
CGREG is x
Modem / GPRS
Sim inserted!
Modem / GPRS
IMEI is x
Modem / GPRS
CCID is '89423053014015087575'
Modem / GPRS
Found default GPRS settings for inserted
SIM card
Modem / GPRS
SIM ready
Modem / GPRS
GPRS> ActivationRequested
Modem / GPRS
GPRS> WaitActivationStart
Modem / GPRS
GPRS> Activating
Modem / GPRS
GPRS> Active
Modem / GPRS
Assigned IP address is 'x'
Modem / GPRS
Telit->Connect request for socket 1...
Modem / GPRS
Sync->Starting connection (x)...
Modem / GPRS
Operator is x
Modem / GPRS
Signal level is x
Sync->OnReceiveAuthResponse: x, y, z,
AuthOK=r
Sync->Connected and authenticated
WriteSlot: Data x bytes, Offsets y bytes
Sync->Utc request RTT x ms
Bootloader
Checking for new FW in external flash...
Bootloader
Found new firmware with size: x B
Bootloader
Checking CRC...
Bootloader
Erasing internal flash...
Bootloader
Flashing new FW...
Bootloader
New FW successfully flashed!
Bootloader
Exiting bootloader...
8021803/2017-11-27|SICK
Irrtümer und Änderungen vorbehalten
Beschreibung
Device is in progress of detecting type of modem and
initializing it
Error condition when modem cannot be detected. Indicates
hardware malfunction.
SMS send and receive subsystem ready
Modem port was successfully opened at baud rate of x
Attempting to change baud rate of modem connection to x
Statements that tells what kind of modem is detected
Driver for "Telit" modem is started
CREG status is x. CREG represents status of registration of
GSM system. CREG can have following statuses:
0 Not Registered, not Searching
1 Registered, home network
2 Not registered, searching
3 Registration denied
4 Unknown
5 Registered, roaming
CGREG status is x. CGREG represents status of registration of
GPRS system. CGREG can have following statuses:
0 Not Registered, not Searching
1 Registered, home network
2 Not registered, searching
3 Registration denied
4 Unknown
5 Registered, roaming
SIM card is detected as inserted
IMEI of the modem
Serial number of the SIM card
Automatic settings for internet access are used for inserted
SIM card
SIM card is ready to be used
GPRS system is requesting activation
GPRS system is waiting for activation to start
GPRS activation has started
GPRS is active
IP address is assigned to device, x
TCP/IP socket connection to server is requested to modem
Server synchronization system is requesting to start
connection to server
Specifies current operator name
Specifies current GSM signal level
Device has received authentication response. Result is r
Connection to server is fully established
Device has sent a chunk of data records to server
Device received time synchronization response from server
At startup, bootloader checks if there is new firmware that
needs to be installed
Appears when bootloader detects new firmware to install
Bootloader starts checking integrity of new firmware
Bootloader is deleting internal flash as a preparation for
install
Bootloader is installing new firmware
New firmware installation was done successfully
Bootloader procedure is finished
B E T R I E B S A N L E I T U N G | Telematic Data Collector
MONITORING
7
