Product Instructions
Use a 5-pole pin plug from the Binder 719 Series.
Pin
1
2
3
4
5
Configurable single input (I/O)
5-pole pin connector, configurable, e.g. as input for foot switch.
For information on configuration of the input, see ToolsTalk MT - Reference -
I/O status.
Use a 5-pole socket plug from the Binder 719 Series.
NOTICE
• This input is not opto-isolated.
Input resistance
NOTICE
• If used to reset the tool, the signal duration must be more than 40 ms.
Pin
1
2
3
4
5
A 2 wire switch (e.g. a reed switch) is connected to pin 1 and 5.
A sensor with PNP output is connected to pin 1, 2 and 5.
Configurable digital inputs and outputs (DIGITAL I/O)
15-pole D-sub socket connector for configurable signals.
Use a 15-pole D-sub pin plug.
8
Output
+24 V
+24 V
Pump on
GND (0 V)
GND (0 V)
Output
+24 V
GND (0 V)
Digital in
© Atlas Copco Industrial Technique AB - 9836 629400 00
EN
Description
Internal +24 V
Internal +24 V
Digital output
Internal 0 V
Internal 0 V
10 kΩ
Description
Internal +24 V
0 V output
Digital input
MT Focus 400
Default
Default
Start tightening
